WCB explosion-proof motor
date：[2018-11-04] pk_hits：
|
 |
|
product manual
Reliable performance
·long lasting
·Simple appearance
·Advanced and reasonable structure
·International standards
·Transport liquid can not contain solid particles
·The conveying temperature is not higher than 70 °C
| 性能參數Technical Specification | |||||||
| 型號 Model | 口徑Size(mm) | 流量Flow(L/min) | 揚程Head(m) | 功率Power(KW) | 電壓Valtage(V) | 轉速Speed(rpm） | 齒輪材質Material |
| WCB-30 | 20 | 30 | 30 | 0.37防爆 | 220/380 | 2800/1450 | 不銹鋼/銅齒輪 |
| WCB-50 | 20 | 50 | 30 | 0.55防爆 | 220/380 | 2800/1450 | 不銹鋼/銅齒輪 |
| WCB-75 | 25 | 75 | 30 | 0.75防爆 | 220/380 | 2800/1450 | 不銹鋼/銅齒輪 |
| WCB-100 | 32 | 100 | 30 | 1.1防爆 | 220/380 | 2800/1450 | 不銹鋼/銅齒輪 |
